PRODUCTS DETAILS

Basic Info.

Model NO.
SewingMachine 014
Transmission Type
Flexible
Automatic Production Line
Comprehensive
Certification
ISO
Flexible Production
Intelligent Manufacturing
Rhythm
Flow Production Line
Production Scope
Product Line
Warranty
on Line After Service
Application Place
Household
Applicable Thickness
Middle Thickness Material
Drive
Electric
Stitch Type
Lock Type
Thread Number
Lock Stitch
Needle Number
Lock Stitch
Mechanical Configuration
Flat-Bed
Weight (Kg)
700kg
Speed
200-3500 Rpm
Stitch Length
0.5-12.7mm
Sewing Range
X:130cm Y:100cm
Transport Package
Wooden Box
Specification
220*132*138cm
Trademark
no brand
Origin
China
Production Capacity
3000pieces/Month

Packaging & Delivery

Package Size
250.00cm * 145.00cm * 150.00cm
Package Gross Weight
720.000kg

Product Description

Large Area Template Lock Stitch Sewing Machine Industrial Programmable Pattern Sewing Machine
Large Area Template Lock Stitch Sewing Machine Industrial Programmable Pattern Sewing Machine
Specification detail :
1) Powerful CNC system
2) High speed sewing, the speed can reach to 3500 rpm
3) Innovative design, The upper shaft mechanism of the nose and the fuselage form a 90° angle,
The part of the head over the line is the front. Easy to thread, easy to manually rotate the handwheel, more convenient to operate.
4) Innovative design Machine head intergral casting, Two servo motors drive the upper shaft and the hook shaft respectively. Small vibration and low noise during high speed sewing.
5) Automatically recognize various CAD file formats of garment factories
6) Template automatic identification system(RFID function) Intelligent recognition with high accuracy.
7) Effective sewing range: X-axis 130cm, Y-axis 100cm
8) Equipped with eight languages
9) Smart touch operation panel,The operation panel supports U disk data transfer/ Read/Storage
10) loT capabilities required for smart factory(WIFI)
11) Imported twice as large hook, reducing the frequency of bottom thread replacement.
12) Circular knife thread trimming device
13) Bottom line detection, saving line and cloth.
14) With intelligent point and line drawing function
15) Optional super function
Laser cutting device


Products Model No:
SewingMachine 014
Sewing range
X: 130cm Y: 100cm
Stitch type
Lockstitch form
Speed
200-3500 rpm (depend on the model, gauge, material,suture situation)
Stitch length
0.5mm - 12.7mm
Needle type
DPx5 (#7-#24); DPx17(#11-#24)
Hook
Imported twice large hook
Storage of templates/pattern
From the original 999 upgrade to unlimited
Program input device
PC USB data cable or U disk
Program memory carrier
EPROM memory
File format
DXF, PLT, AI, etc.
Power supply
220V
System brand
X
Gross weight
700KG
Volume
220*132*138cm (LxWxH)- 4.000 CBM
