Topwisdom Computer 2 Head Computerized Cap Embroidery Machine

Topwisdom Computer 2 Head Computerized Cap Embroidery Machine - Factory direct embroidery equipment for high-quality designs. Order now for fast shipping!
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
Q401/ Q402/ Q403
Needle Number
Twelve Needles
Head Number
Double
Embroidery Type
Towel Embroidery, Clothing Embroidery, Hat Embroidery, Flat Embroidery
Embroidery Area
500*400
Main Motor
Servo Motor
Xy Motor
Stepper Motor
Speed
1000rpm
Computer
10" Touch Screen Computer
Language
Support 12 Languages
Power
100V/60Hz - 240V/50Hz
Transport Package
Wooden Package
Specification
CE, ISO9000
Trademark
wonyo
Origin
China
HS Code
8447902000
Production Capacity
500sets /Year

Product Description

Topwisdom Computer 2 Head Computerized Cap Embroidery Machine

Suitable for all commercial embroidery needs, 2 heads embroidery machine can embroider caps, flats, bags, finished garments and more. Redesigned to carry a larger sewing field and a smaller sewing arm for difficult areas!

https://youtu.be/5F6cNtU3jc4




Topwisdom Computer 2 Head Computerized Cap Embroidery Machine
Topwisdom Computer 2 Head Computerized Cap Embroidery Machine



1. Machine Specifications

Specifications
Multi Function Cap/ T-shirt/ Flat/ Garment/ Jacket/ Leather/ 3D Embroidery
Speed Speed: 1000RPM
Embroidery Area 500*400mm per head
Motor Maine Axis Servo Motor * 1
X-Y Axis Stepper Motor * 2
X, Y Driving  Reinforced high speed linear guide rail
Control Board Standard: 10" True Color LCD Screen
Hook Japanese Rotary Hook
Memory Capacity Standard: 20,000,000 Stitches matched with 200 patterns
Max. Color Change Auto start and color change, 200 times color change setted
Design Input By U disk, USB and Transmission from PC to Control System
Readable Data Compatible with designs of Tajima (DST), Barudan (DSB) and etc.
Safety Device Standard: Emergency Stop
Multi Languages 12 languages: Chinese, English, French, Russian, Dutch, Spanish, Portuguese, Turkish, German, Arabic, Thai, Vietnamese
Main Parts Japanese Rotary Hook, Germany Groz-Beckert Needles, Italy Brand Belt
Embroidery Trimming Automatic trimming
Voltage  AC110-220V, adaptable for any voltage, 50-60HZ
Optional Device Sequin, Double Sequin, Boring, Cording, Laser trace Device, 8-in-1 Hoop Set, Shoes Device

2. Control System (10"New Technology Screen System, Direct Photo Embroidery, no need degitizing)

 A. Color LCD display showing real time stitching
B. Manual, Semi-auto, Auto Color Change
C. Function keys including Menu, Speed up and slow
D. Multi languages available
E. Frame-moving keys, Manual Trimming
F. DOT ket to return to 100 degree
G. Start, Stop, and emergency Stop
H. Embroidery Status (Page Up/Page Down), USB Input,
I. Parameter Settings, Clear, ESC, Enter, etc.
J. Numeric keys for selection of needles

Control System
Automatic trimming YES
Automatic cutting YES
Automatic color change  YES
Thread broken detecting YES
Memory size 20,000,000 stitches/200 embroidery design patterns
Font/letter software Available
Error code YES
Real-time stitching YES
Different languages setting YES
USB port, network transferring design  YES
Led light  YES


3. Frames/ Hoops Included (Hoops are for Finished Garments Embroidery

A. 2 sets of 9*9 cm T-shirt hoop per head        Total: 4 sets
B. 2 sets of 12*12 cm T-shirt hoop per head       Total: 4 sets
C. 2 sets of 15*15 cm T-shirt hoop per head       Total: 4 sets
D. 2 sets of 19*19 cm T-shirt hoop per head       Total: 4 sets
E. 2 sets of 29*29 cm T-shirt hoop per head       Total: 4 sets
F. 1 piece of Flat Embroidery Frame: 500*800mm


4. Caps Embroidery Device Included (Cap rings * 4, Hoop station * 1, Cap driver * 2)

Topwisdom Computer 2 Head Computerized Cap Embroidery Machine
5. Groz-beckert Needles and Japan Koban Rotary Hook Included
6.
Standing table  with wheels included
7.
Bobbin Winder  included
8.
16 GB  USB driver included
9.
Instruction  Manual
10.
A whole set free easy damaged spare parts  for your future replacement
11.
100 free designs  for testing your machine.

Packing and Delivery
Topwisdom Computer 2 Head Computerized Cap Embroidery Machine
Package
Size 1240*1030*1320mm
Weight 329KGS
Package details The normal package is wooden box(Size: L*W*H).
But it's ok to pack it according to customers special request.

Customers Feedback
Topwisdom Computer 2 Head Computerized Cap Embroidery Machine
Topwisdom Computer 2 Head Computerized Cap Embroidery Machine
Topwisdom Computer 2 Head Computerized Cap Embroidery Machine

Topwisdom Computer 2 Head Computerized Cap Embroidery Machine


FAQ Hot Questions


Q: Is this a trustable long-term strategic partner?



A: Just ask our customers, view our company profile, assessment of capability, factory glimpse,
and the honor we had. And why not contact us or pay a visit to us?

Q: What service will I get with this buying?

A: Simply at your service: available consultancy before sales, easy communication during sales,
easy payment term, smooth and safe delivery of guaranteed quality, and assured timely services after sales.

Q: What kind of embroidery work and embroidery machine do I need?

A: Think: ready-made garment/cap/hat, or garment before sewing, or just flat fabric?

Normal flat stitch, or special chenille/chain/loop stitch, or sequin/paillette,
or cord/tape/ribbon to add value to your embroidery?

Q: How many heads do I need and what embroidery area on each head?

A: Think: how big is your factory and how much is your expected production?

The embroidery area on each head depends on the maximum area of your embroidery design to run.

Q: How many stitches do I get per minute (SPM) on each head?

A: High speed model gives max. 1200SPM,

Normal speed model gives max. 1000SPM,

Lower speed model gives max.850SPM.

Q: Do I need the Elite model or economy model?

A: Think: How much would you pay for a machine? What we offer is what you need!

Q: Can I represent and sell ORDER machines in my market?

A: Welcome to join WONYO family and grow to be a strong distributor.

Looking for agent from all over the world!

Welcome to contact Forcen
Topwisdom Computer 2 Head Computerized Cap Embroidery Machine
